highlights
- weld seam limitation
0.2 mm or 2.0 mm (manually adjustable) - Angle adjustment from 30° – 180°
- Welding parameters individually adjustable
- Maximum profile height 200 mm
- Long lifetime
Options
- Digital angle display
- 450mm heating element
- Convenient insertion of the 4th corner
- support arms
![](https://www.finke-maschinen.de/wp-content/uploads/AKS1150_2-667x400.jpg)
Highest accuracy
Due to the direct measurement on the stop bar, the digital angle display and the comfortable clamping lever adjustment guarantee you absolute precision.
![](https://www.finke-maschinen.de/wp-content/uploads/AKS1150_1-667x400.jpg)
Universally applicable
The manual adjustment of the weld seam limitation from 0.2 mm to 2.0 mm ensures outstanding machining results with white and foil-coated profiles.
![](https://www.finke-maschinen.de/wp-content/uploads/AKS1020_1-f7959ef8-1-667x400.jpg)
Optimal adjustment
With the large heating element (450 mm length), even the widest profile cross-sections, e.g. B. Front door profiles can be welded at an angle of up to 30°.
